Brand: OMRON
Model Number: NX102-1200
Status: new original in stock
Warranty: one year
MOQ: no
Guaranteed new, original Omron products ensuring optimal performance.
Swift, efficient delivery to keep your projects on track.
Worldwide support and services, tailored to your needs.
| Product name | Specifications | Model | ||||
|---|---|---|---|---|---|---|
| Program capacity |
Memory capacity for variables |
Maximum number of used real axes | ||||
| Motion control axes |
Single-axis position control axes |
|||||
| NX102 CPU Unit  |
5 MB | 1.5 MB (Retained during power interruption)/32 MB (Not retained during power interruption) |
12 | 8 | 4 | NX102-1200 |
| 8 | 4 | 4 | NX102-1100 | |||
| 6 | 2 | 4 | NX102-1000 | |||
| 4 | 0 | 4 | NX102-9000 | |||
| NX102 Database Connection CPU Unit  |
12 | 8 | 4 | NX102-1220 *1 | ||
| 8 | 4 | 4 | NX102-1120 *1 | |||
| 6 | 2 | 4 | NX102-1020 *1 | |||
| 4 | 0 | 4 | NX102-9020 *1 | |||
| Item | Specification | |
|---|---|---|
| Model | NX102-[][][][] | |
| Enclosure | Mounted in a panel | |
| Dimensions (mm) *1 | 72 × 100 × 90 mm (W×H×D) | |
| Weight *2 | 390 g max. | |
| Unit power supply |
Power supply voltage | 24 VDC (20.4 to 28.8 VDC) |
| Unit power consumption *3 |
5.80 W max. | |
| Inrush current *4 | For cold start at room temperature: 10 A max./0.1 ms max. and 2.5 A max./150 ms max. |
|
| Current capacity of power supply terminal *5 |
4 A max. | |
| Isolation method | No isolation: between the Unit power supply terminal and internal circuit | |
| Power supply to the NX Unit power supply |
NX Unit power supply capacity |
10 W max. |
| NX Unit power supply efficiency |
80% | |
| Isolation method | No isolation: between the Unit power supply terminal and NX Unit power supply | |
| I/O Power Supply to NX Units | Not provided *6 | |
| External connection terminal |
Communication connector |
RJ45 for EtherNet/IP Communications × 2 RJ45 for EtherCAT Communications × 1 |
| Screwless clamping terminal block |
For Unit power supply input and grounding (Removable) | |
| Output terminal (service supply) |
Not provided | |
| RUN output terminal | Not provided | |
| NX bus connector | 32 NX Units can be connected | |
| Item | Specification | |
|---|---|---|
| Enclosure | Mounted in a panel | |
| Grounding method | Ground to less than 100 Ω. | |
| Operating environment |
Ambient operating temperature |
0 to 55°C |
| Ambient operating humidity |
10% to 95% (with no condensation) | |
| Atmosphere | Must be free from corrosive gases. | |
| Ambient storage temperature |
-25 to 70°C (excluding battery) | |
| Altitude | 2,000 m max. | |
| Pollution degree | 2 or less: Meets IEC 61010-2-201. | |
| Noise immunity | 2 kV on power supply line (Conforms to IEC 61000-4-4.) | |
| Overvoltage category | Category II: Meets IEC 61010-2-201. | |
| EMC immunity level | Zone B | |
| Vibration resistance | Conforms to IEC 60068-2-6. 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz, acceleration of 9.8 m/s2 100 min each in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total) |
|
| Shock resistance | Conforms to IEC 60068-2-27. 147 m/s2, 3 times in X, Y, and Z directions |
|
| Battery | Life | 5 years (Power ON time rate 0% (power OFF)) |
| Model | CJ1W-BAT01 (sold separately) | |
| Applicable standards *1 |
EU Directives | EN 61131-2 |
| cULus | Listed UL 61010-2-201 and ANSI/ISA 12.12.01 | |
| Shipbuilding Standards | NK, LR | |
| Other than the above. | RCM, KC, and EAC | |
